10 Hidden Tractor Features Most Owners Don’t Know About

You might have been operating your tractor and never discovered these!

Regardless if this is your first tractor, or you’ve been doing this for ten years, there’s a very good chance that there are a couple of tractor features still on your machine that you’ve never used. Here are ten manufacturer-installed features of tractors (found on many of the subcompact and compact tractors from John Deere, Kubota, Mahindra, and other major brands) that even some experienced operators often fail to utilize.

Prefer to watch? Check out our full video breakdown of these hidden features in action:

Don’t forget to subscribe to the Good Works Tractors YouTube channel for more compact tractor hacks, safety tips, and attachment reviews.

1. Reverse Override (RIO): Mow in Reverse Safely

The RIO (Reverse Override) tractor features allow you to continue using your mower while traveling in reverse. When mowing around trees, landscaping beds, or tight corners, the RIO feature lets you reverse without shutting the mower deck off. You will have the ability to adjust the height of your mower deck by having the RIO feature available to use only when you need it, allowing you to quickly return to the position that you want your mower set.

If your mower has an RIO, you will have a pull-style knob on your mower’s control panel or a small yellow push button located to the left of your seat.

To use the RIO tractor feature:

• First use the disengaged position of your hydrostatic pedal to allow you to turn your mower.
• Once you’re on your way, depress the RIO button and hold it down while you press the push pedal.
• At this point, the deck continues to work while you are moving backward as long as you have pressed down on the RIO button.

2. Pre-Wired Accessory Harnesses: Already on the Tractor

Typically, you’ll find that many John Deere (and other manufacturers) tractors are wired with additional wiring harnesses that tuck low on the frame from the factory. These usually have two small connectors (two separate connectors; just ready to be connected) that you can use once you flip the light switch on; this means that whatever you have attached to those connectors will automatically come on when you turn on your lights.

Most people use them to run auxiliary work lights on the ROPS or front frame. However, you can also use them to power controls for electronic attachments and any 12-volt accessories you wish to operate on the tractor.

To find your pre-wired accessory harnesses:

Follow the rear or underbelly of the tractor and find the wiring loom leading to the connectors (they refer to a bullet connector in the parts book).

3. Loader Tube Storage: Hidden Right in Plain Sight

The empty hollow square tube in the front-end loader is one of the perfect tractor hacks for you to use as some storage. A commonly used, proven method for storing chains (tie-down straps, hand tools, etc.) is to cut a length of PVC pipe to fit, load it with the items you want to store, place a cap on one end so it will be able to slide in and out easily, and then insert the PVC pipe into the unused hollow square tube located in the front-end loader.

Compact tractors tend to come up short when it comes to storage space, so all additions of storage count! Storing a tow chain within a capped loader tube means that you’ll have access to it at any time without causing it to rattle or get forgotten.

4. Three-Point Hitch Float Position: For Finish Mowers & Brush Hogs

The float position on a three-point hitch of many tractors, including the John Deere 4M series, is activated by removing a pin, pulling out a small plug, and rotating it 90 degrees. This allows the hitch and implement to float, i.e., the implement follows the surface contours of the ground rather than remaining at a fixed height above the ground.

This is especially beneficial for finish mowers and brush hogs since they operate by riding on top of the surface rather than digging into the ground. A locked hitch at a fixed height when mowing on rolling terrain will cause the mower to scalp the tops of the hills, causing damage, while at the bottom of a hill, it will cause the mower to bog down or stall. In either case, using the float position will help prevent issues with either the mower or the hitch. For ground-engaging implements such as tillers or disc harrows, continue using the normal position since downward pressure is required for proper operation.

5. Loader Lockout Valve: One of The Critical Tractor Safety Features

All front-end loader-equipped tractors that we have seen have loader lockout valves, which are a small knob that is typically located near the joystick. When the knob is pushed in, the loader will no longer function due to the joystick being in a disabled state. In other words, if the loader is raised and the joystick is pushed or bumped, it will not raise or lower (move) independently of the original state.

This is one of the best tractor safety features that should be engaged whenever a person is working under a raised loader (e.g., washing under the mower deck, servicing the loader itself, or just having it sit raised in an area where there are a lot of people walking around). However, be aware that these tractor features are not commonly used; consequently, it may become stuck on an older or used tractor. However, applying penetrating oil and exercising the valve in both directions (back and forth) often frees the loader from being stuck on the track.

6. Loader Joystick Float: The Fifth Function Operators Forget

Most operators are familiar with four loader functions: raise, lower, curl, and roll back functions, but one of the most beneficial features of tractor is the fifth function known as float, which is activated by pushing the joystick past the normal lower detent position. When in floating mode, hydraulic pressure has been completely relieved so that the position of your tractor bucket is controlled solely by gravity, using contact with the ground rather than hydraulic pressure from the cylinders.

The floating mode of operation will make loader operations significantly easier to perform in several instances, including but not limited to:

• Back dragging or spreading loose material: Easily spread mulch, topsoil, or gravel without digging into the ground. Utilizing a specialized materials bucket with a smooth bottom or adding a protective edge makes back-dragging seamless and keeps you from chewing up your work area.
• Plowing or pushing snow: Prevent hydraulic down pressure from gouging concrete or asphalt driveways while reducing wear on attachment cutting edges. Using a dedicated containment tool like the GWT VersaPusher lets you clear paths cleanly in float mode, and it reverses into a high-volume materials bucket when winter ends.

Feathering material: Move and level material with significantly more precision than standard down pressure allows. For the ultimate smooth finish, operators often pair float mode with a specialized grading attachment, which naturally rides along the ground to shave high spots and fill in low points effortlessly.

7. Electric & Hydraulic-Free Grapple Options

Approximately 90% of owners of compact or sub-compact tractors do not have a third-function hydraulic kit installed or a diverter valve on their machine. Historically, this has prevented these customers from being able to use a grapple on their tractors.



This is changing in a very positive way recently, and this is one of the most exciting new things among the tractor features coming out as a compact tractor feature.

An electric grapple can be connected directly to the tractor battery, completely bypassing the hydraulic system; these units can be installed in less than 30 minutes. Electric grapples are compatible with both the John Deere style ‘quick-attach’ (235, 245, 252, 273 etc.) and also with the skid-steer style of quick attach (for example: Kubota).

As a lower-cost alternative, a mechanical brush crusher can be bolted onto the front of the loader arms without having to be connected to the hydraulic or electric circuits on the tractor. Mechanical brush crushers are perfect for moving brush piles and light debris across a property without having an implemented dedicated hydraulic circuit available on the tractor.

8. The Accessory Slot on Your Loader Upright

One tractor feature of John Deere Front-End Loaders that most users overlook is a ‘spare’ hole or slot located at the top of each loader’s vertical support shaft, which can be used to hold various tractor attachments but is very rarely utilized. Most people wouldn’t notice this unless someone told them about it.

A simple addition that can be used with these slots is mirrors (recommended if you drive backwards along a road or work in confined areas), and they have been utilized by many operators as an alternative means of holding small tools, portable radios, and cups.

For users of other manufacturers’ tractors, such as Kubota or Mahindra, using their creativity with brackets typically yields similar results. Good Works Tractors offers different types of mirrors designed specifically for the John Deere loader vertical mount holes.

9. Glow Plugs & Air Intake Heaters: Don’t Skip This on Cold Mornings

If you own a diesel tractor and live in a cold climate, cold-weather starting assistance is critical. This essential feature is usually represented by a specific indicator light right on your dashboard.

There should be some kind of cold-weather starter assistance to help start your diesel tractor in cold weather; this could be glow plugs, an air intake heater, or both. Most modern tractors come equipped with an electronic display, so instead of seeing an illuminated orange coil on the dashboard, you might see the message “Wait to Start.” Some larger tractors will only activate the glow plugs when the temperature is cold enough, so you may not see this indicator all the time when you start your diesel tractor. If you are trying to be extra careful about your diesel tractor starting in the snow, you can safely wait to start it before turning the key two or three times.

10. Hydraulic Drop Rate / Draft Control: Slow Down Your Three-Point

One of the overlooked features of tractor is the rate of drop control valve, which is usually located next to the operator’s platform or under the operator’s seat. This system controls how quickly the 3-point hitch goes up and down.

For fine adjustment applications, you will find it useful for the following types of equipment:

• Box Blades
• Rear Blades
• Tillers
• Precision Grading Equipment

Slower movement will give you smoother control and better grading accuracy.
