IronCraft UM Medium Duty Gear-Drive Rotary Tiller Highlights
In the middle of the Gear Drive Tillers series lies IronCraft’s UM Tillers. The UM line is Medium-Duty 3-Point tillers meant for compact tractors with 25–50 PTO horsepower.
With a 60 or 72 inch working width, you’ll be best not to use a tiller much narrower than the footprint of your tractor (while not exceeding the required hp) so you don’t compact freshly tilled soil as you go.
The UM Series tills to a very respectable 7 inch depth with either model.
Compatible with a Cat I 3-Point Hitch.
All specs are below for both widths of the tiller.
Available in IronCraft Gray only.
Specs
| Product Family | UM Series | UM Series |
|---|---|---|
| Product | UM-56 | UM-72 |
| Description | 60″ Medium Duty Gear Drive Tiller |
72″ Medium Duty Gear Drive Tiller
|
| Rotation | Forward | Forward |
| RPM | 540 | 540 |
| HP Required | 25 – 50 | 25 – 50 |
| Working Width | 60″ | 72″ |
| Max Working Depth | 7″ | 7″ |
| # of Flanges on Rotor | 7 | 9 |
| # of Tines per Flange | 6 | 6 |
| Total # of Tines | 42 | 54 |
| Rotor Thickness or Diameter | 3″ | 3″ |
| Rotor Swing Diameter | 17″ | 17″ |
| Overall Width | 65″ | 78″ |
| Weight (lbs) | 578 lbs | 684 lbs |
| Hitch | Cat 1 | Cat 1 |
Lifetime Warranty
Increase the standard manufacturer’s warranty to GWT’s Lifetime Warranty.
What is covered
Your GWT Lifetime Warranty covers issues stemming from the craftsmanship of the product, like broken welds, torn steel, or improper fit. Tractor attachments are generally designed to be used in harsh environments, so normal wear-and-tear is not covered (things like lost paint or chipped paint, scratches, dents, or bent teeth).
We will repair or replace, at our discretion, your attachment/product under the Lifetime Warranty, if purchased.
What isn’t covered
Any shipping necessary for repair or replacement, as well as transportation costs are not covered under the factory warranty. Lost time and down time are not covered. Replacement parts are covered, but not labor costs.
If damage occurs from improper use (a use other than what the product is marketed for), the warranty is void. Damage caused to your tractor while using an attachment will not be covered.
Your warranty is non-transferable, meaning it exists as long as you’re the owner and operator of the product.
